Product Details:
|
| Model NO.: | Ge-Jm650 | Etching Type: | Double Spray |
|---|---|---|---|
| Precision: | Precision | Condition: | New |
| Model: | Ge-Jm650 | Accuracy: | +/- 0.02mm |
| Wokring Width: | 650mm (Can Be Order) | Etching Area Length: | 2meter |
| Acid Solution: | Ferric Chloride | Power: | 11.5kw/380V |
| Etching Width: | 650mm | Tolerance: | 0.02mm |
| Lead Time: | 15days | Transport Package: | Standard Export Wooden Case, Wooden Packaging |
| Specification: | CE; ISO | Trademark: | GOLDEN EAGLE |
| Origin: | China | HS Code: | 84862090 |
| Supply Ability: | 15sets/Month | After-sales Service: | After 1year,Once Some Components Are Broke |
| Warranty: | After 1year,Once Some Components Are Broke | Type: | Photochemical Etching Machine |
| Object: | Metal | Usage: | Marking & Lettering, Corrosion & Hollowed-out |
| Certification: | CE |
| Auto Double Side Etching Machine | |
| Power | 16KW/380V/50HZ |
| Working width | 650mm |
| Etching area | Length:2000mm |
| Pump:4KW/set,2sets | |
| Double Spraying & Oscillate Pressure control for every spray pipe |
|
| Heater: Titanium pipe,3KW/1groups | |
| Cooling: Titanium pipe,1set | |
| Working Temp:37~55ºC | |
Rinse area |
Length: 500mm, 1parts |
| Pump:2.2KW/set,1sets | |
| Double spraying | |
| Machine Size | 4500*1650*1700mm |
| Weight | About 1000kgs |
Process:
Load (500mm) → Etching1,2 (2000mm)→Pressure rinse1(500mm)→Unload (500mm)
