Product Details:
|
| Model NO.: | GE-SK-9 | Etching Type: | Double Spray |
|---|---|---|---|
| Precision: | Precision | Condition: | New |
| Working Width: | 650mm (Can Be Order) | Tolerance: | 0.02mm |
| Plate Thickness: | 0.05mm ~3.2mm | Application: | Single Board, Double Board, Multi-Layer Board |
| Model: | Ge-Sk9 | Power: | 380V/50Hz/60Hz |
| Working Height: | 850mm (+/50mm Adjust) | Max Board Size: | 500*500mm |
| Min Board Siz: | 120*80mm | Conveyor Speed: | 0.5~6m/Min |
| Transport Package: | Standard Export Wooden Case | Specification: | CE |
| Trademark: | Golden Eagle | Origin: | Beijing, China (Mainland) |
| HS Code: | 84862090 | Supply Ability: | 20sets/Month |
| After-sales Service: | 1year. After 1year,Once Some Components Are Broke | Warranty: | 1year. After 1year,Once Some Components Are Broke |
| Type: | Photochemical Etching Machine | Object: | Metal |
| Usage: | Corrosion & Hollowed-out | Certification: | CE |
| Machine Model | GE-SK12 |
| Machine Power | 108KW/380V/50HZ |
| Working Width | 450mm |
| Working height | 900mm±25mm |
| Working Temperature | 37~45ºC |
| Etching Type | Double sided etching strip swaying |
| Heating System | Titanium tube heating |
| Etching Pump | 7.5KW/380V/50Hz |
Working Form |
Spray type, horizontal track feeding (Stepless speed regulation) |
| Machine Size | 17600*1700*1700mm (L*W*H) |
| Machine Weight | 6200kgs |
Technological process
Load(500mm) - Etch 1 (2000mm) - Etch 2 (2000mm) - Etch 3 (2000mm) - Etch 4 (2000mm) - Etch 5 (2000mm) - Etch 6 (2000mm) - Clean (1500mm) - Unload (500mm)
1.Q:Are you trading company or a factory ?
A: We are manufactory and We have import and export License .
2.Q:Where is your factory ?How Can I visit there?
A: Our factory is located in Beijing, the capital of China,Warmly welcome to visit us.
3.Q:How can I get some samples ?
A: we are honores to offer you samples,please contact us anytime !
4.Q: How does your factory do regarding quality control ?
A: Quality is priority .Golden Eagle people always attach great importance to quality controlling from A to Z.
5.Q:Why us ?
A: 1. 20 years machine manufacture experiences !
2. More than 10 years good credit supplier on Made-in-China
3. satisfaction or we'll refund or rerun-your choice
4. Etching technology can be provided for free to our customer by our well-trained and professional engineers and staffs.
Contact Person: Mrs. liu
Tel: 15010608128
