Product Details:
|
| Model NO.: | GE-T650 | Etching Type: | Double Spray |
|---|---|---|---|
| Precision: | High Precision | Condition: | New |
| Power: | 10.5kw/380V/50Hz | Working Width: | 650mm |
| Etching Area: | 650mmx1000mm | Working Type: | Double Spraying |
| Etching Temp: | 37~45ºC | Heater: | 3kw Titanium |
| Cooling: | Titanium Pipe | Etching Pump: | 4kw*1set |
| Leading Time: | 25days | Transport Package: | Wooden Package |
| Specification: | 650mm | Trademark: | Golden Eagle |
| Origin: | China | HS Code: | 84862090 |
| Supply Ability: | 100sets/Year | After-sales Service: | 1year. After 1year,Once Some Components Are Broke |
| Warranty: | 1year. After 1year,Once Some Components Are Broke | Type: | Electrical Etching Machine |
| Object: | Metal | Usage: | Corrosion & Hollowed-out |
| Certification: | CE |
1.This machine is sealed,because the chemical is very strong and big smell,so machine is sealed;
2.Machine is double spraying, top and bottom, can control it separately;
| Metal Etching Machine | |
| Power | 10.5KW/380V/50HZ |
| Working width | 650mm |
| Etching Part | 650mmx1000mm |
| Double Spraying | |
| Etching temp: 37~45ºC | |
| Heater: Titanium,3KW | |
| Cooling : Titanium Pipe | |
| Etching pumps: 4KW, 1 set | |
| Spray pipe: 14pcs ,for up and down | |
| Nozzles: Fan-shaped,91nozzles | |
| Rinse Part | 650mmx1000mm Pump: 1.1KW,2sets Double spraying |
| Machine Size | 3500*1600*1550mm |
| Weight | About 800kgs |
| Process: enter (500mm) -- etching (1000mm) -- rinse 1,2 (1000mm)--- out (500mm) | |
| Automatic Control System: Conveyor speed;pressure;temperature;double filter system | |
| Introduction | |
| 1.This machine is sealed,because the chemical is very strong and big smell,so machine is sealed; 2.Machine is double spraying, top and bottom, can control it separately; 3. Materials can be Steel, Stainless steel, Brass, aluminum,Si,Cu,titanium etc. | |
rocess:
Load (500mm) → Etching1,2 (2000mm)→Pressure rinse1(500mm)→Unload (500mm)
Feature:
Beijing Golden Eagle Electronic Equipments Co.,Ltd located Beijing, the capital of China. We manufacturer of printed circuit board (PCB) manufacturing equipment & machinery including chemical etchers, strippers, cleaners & dryers. PCB Etching Equipment and Wet processing equipment and Chemical Milling machine and Metal etchers.
We can supply whole processing equipments and support with whole processes technique training. maily used In Metal etching,PCB etching ,FPC etching,Precision parts etching,Cutting Dies & Hot stamping dies etching,nameplate & medal etching, Press plate etching,Decoration plate etching and so on. material can be stainless steel,copper,brass,aluminum,zinc,magnesium and so on.
In the past 20 years, we sold variety of etching machines to Australia,ARGENTINA,Armenian,Belarus,Bulgaria,Belgium, Canada,Colombia,Czech Republic,Egypt,FRANCE,INDIA,IRAN,Kuwait,Lebanon,MEXICO,Malaysia,PORTUGAL,QATAR,Romania,Saudi Arabia,Singapore,Sweden,SPAIN, Sri Lanka,THAILAND,TURKEY,U.A.E.,USA,United Kingdom,and many other countrys.
Our mission is to deliver high-quality, reliable manufacturing solutions that are designed to meet each customer's unique needs.
1.Q:Are you trading company or a factory ?
A: We are manufactory and We have import and export License .
2.Q:Where is your factory ?How Can I visit there?
A: Our factory is located in Beijing, the capital of China,Warmly welcome to visit us.
3.Q:How can I get some samples ?
A: we are honores to offer you samples,please contact us anytime !
4.Q: How does your factory do regarding quality control ?
A: Quality is priority .Golden Eagle people always attach great importance to quality controlling from A to Z.
5.Q:Why us ?
A: 1. 20 years machine manufacture experiences !
2. More than 10 years good credit supplier on Made-in-China
3. satisfaction or we'll refund or rerun-your choice
4. Etching technology can be provided for free to our customer by our well-trained and professional engineers and staffs.
1. Customized.
2. Free training.
