Product Details:
|
| Model NO.: | Jm650 | Etching Type: | Double Spray & Oscillate |
|---|---|---|---|
| Precision: | Precision | Condition: | New |
| Power: | 31.5kw/380V/50Hz | Working Width: | 650mm |
| Working Temperature: | 37~45centigrade | Heat System: | Titanium, 5.5kw*3PCS |
| Machine Size: | 9500*1700*1650mm | Transport Package: | Wooden Package |
| Specification: | CE | Trademark: | Golden Eagle |
| Origin: | Beijing, China (Mainland) | HS Code: | 8486209000 |
| Supply Ability: | 35sets/Month | After-sales Service: | 1year. After 1year,Once Some Components Are Broke |
| Warranty: | 1year. After 1year,Once Some Components Are Broke | Type: | Photochemical Etching Machine |
| Object: | Metal | Usage: | Corrosion & Hollowed-out |
| Certification: | CE | Samples: | US$ 500/Piece 1 Piece(Min.Order) | Request Sample |
| Auto Double Side Etching Machine | |
| Power | 16KW/380V/50HZ |
| Working width | 650mm |
| Etching area | Length:2000mm |
| Pump:4KW/set,2sets | |
| Double Spraying & Oscillate Pressure control for every spray pipe | |
| Heater: Titanium pipe,3KW/1groups | |
| Cooling: Titanium pipe,1set | |
| Working Temp:37~55ºC | |
Rinse area | Length: 500mm, 1parts |
| Pump:2.2KW/set,1sets | |
| Double spraying | |
| Machine Size | 4500*1650*1700mm |
| Weight | About 1000kgs |
Process:
Load (500mm) → Etching1,2 (2000mm)→Pressure rinse1(500mm)→Unload (500mm)
Feature:
Service:
Contact Person: Mrs. liu
Tel: 15010608128
