Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy

Name: Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy
Brand: Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy
SKU: Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy
Rating: 4.5 (103 reviews)

All Products

Etching Machine
(55)

Decorative Board Etching Machine
(21)

Metal Plate Etching Machine
(79)

Flexible Cutting Die Etching Equipment
(48)

Double Side Chemical Milling Equipment
(2)

Double Side PCB Etching Machine
(36)

PCB Etching Machine
(22)

Hot Stamping Dies Making Machine
(12)

PCB Laboratory Equipment
(6)

Certification

I'm Online Chat Now

Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy

Large Image : Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy

Product Details:

Contact Now

Flexible Die Etching Machine GE-DB5060 High Precision And Accuracy

Description

Certification:	CE	Supply Ability:	25sets/Month
Model NO.:	GE-DB5060	Etching Type:	Vertical Spray Etching
Precision:	High Precision	Condition:	New
Working Size:	500*600mm	Accuracy:	+/- 0.02mm
Machine Size:	185015001550mm	Application:	Flexible Die Can Cut Paper, Sticker, Film Etc.
Control:	Control Panle Or PLC	Current:	AC
Laser Type:	Chemical Acid Etching	Model:	Ge-Db5060
Package:	Wooden Package	Leading Time:	15days
Transport Package:	Standard Export Wooden Case	Specification:	CE
Trademark:	GOLDEN EAGLE	Origin:	China
HS Code:	84862090	After-sales Service:	1year. After 1year,Once Some Components Are Broke
Warranty:	1year. After 1year,Once Some Components Are Broke	Type:	Photochemical Etching Machine
Object:	Metal	Usage:	Mould

dB5060 flexible die etching machine

DB5060 Steel Flexible Dies Etching Machine

dB5060 cutting die etching machine

dB5060 Flexible Magnetic Dies Etching Machine

DB5060 Photo Etching Machine for flexible dies

DB5060 Steel Flexible Dies Etching Machine

Power:	7.5KW/380V
Working Size:	500*600mm
Etching type:	Vertical spraying
Working Temp:	40~55 degrees
Heat System:	Titanium, 3KW
Cool System:	Titanium Pipe
Motor power:	4KW/380V
Machine Size:	195013501550mm
Weight About;	550kgs

Control system: Temperature, Speed, Pressure, Network Filter

Making Process: Dry film photoresist & ink --- expose --- developer --- etching -- stripper --- cleaning --- drying --- CNC engraving ---- nickel & chrome plating --- finished

Introduction:
1. Flexible Dies Etching machine is a photoengraving machines for steel or high-carbon steel plate mold pretreating etching to advance following engraving processing.
2. After etching, the cutting knife-edge and knife depth is etched out.
3. Then the following CNC engraving Knife sharpening works is easy and fast.
4. It can save lots of unnecessary cost compare to use CNC engraving to working completely.
